Hollow shaft electric motor
Hollow shaft electric motors
B3/B14 Electric motor version
B3/B14 Electric motor version
| CODE | MOTOR CONTRUCTION SHAPE | WEIGHT | RATED POWER OUTPUT | SPEED | VOLTAGE | FOR PUMP SERIES | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-430.0 | IEC80 | 12.0 | 0.75 | 0.55 | 1450 | 230V | FOG |
| 1.099-437.0 | IEC80 | 12.0 | 1.0 | 0.75 | 1450 | 230V | FOG |
| 1.099-438.0 | IEC90S | 16.0 | 1.5 | 1.1 | 1450 | 230V | FOG |
| 1.099-422.0 | IEC90L | 16.0 | 2.0 | 1.5 | 1450 | 230V | FOG |
| 1.099-413.0 | IEC100 | 21.0 | 4.0 | 3.0 | 1450 | 230/400V | NMT Car Wash, NMT High Temperature, NHDP 120-C, NHDP 150-C, NHDP 200-C, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical |
| 1.099-414.0 | IEC100 | 23.0 | 5.5 | 4.0 | 1450 | 230/400V | NMT Car Wash, NMT High Temperature, NHDP 150-C, NHDP 200-C, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical |
| 1.099-416.0 | IEC112 | 33.0 | 7.5 | 5.5 | 1450 | 230/400V | NMT Car Wash, NMT High Temperature, XLTI High Temperature, NHDP 200-C, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical |
Flanges
Flanges
for electric motors
| CODE | MOTOR CONTRUCTION SHAPE | FOR PUMP SERIES |
|---|---|---|
| 1.099-528.0 | H90 B14 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.099-529.0 | H100/112 B14 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.099-530.0 | H100/112 B14 | NMT, NPM, NMT Car Wash, NMT High Temperature, NMT Nickel-Plated, NPM Nickel-Plated, NLTI, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical |
| 1.099-531.0 | H132 B14 | NMT, NPM, NMT Car Wash, NMT High Temperature, NMT Nickel-Plated, NPM Nickel-Plated, XLTI, XLTI High Temperature, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, NMT - Car Wash Heavy Duty, NMT Chemical, XLTI Chemical, XLTI Stainless Steel Chemical, NMT Stainless Steel Chemical, PXI Heavy Duty |
| 1.099-532.0 | H160 B5 | XLTI, XLTI High Temperature, PXI 350, XXT, XLTI Atex, PXI 500, XXT High Temperature, XLTI Chemical, XLTI Stainless Steel Chemical, PXI Heavy Duty |
Flexible coupling
Flexible couplings for electic motors
Gearboxes
Gear reduction boxes for petrol engines
| CODE | MOTOR SHAFT DIAMETER | MOTOR FLANGE | INLET SPEED | OUTLET SPEED | MAX POWER | RATIO | FOR PUMP SERIES |
|---|---|---|---|---|---|---|---|
| Ø | TYPE | RPM | RPM | KW | N1 / N2 | ||
| 1.099-675.0 | 3/4" | SAE J609a | 3400 | 1450 | 4.8 | 2.3 | NHDP 120, NHDP 150 |
| 1.099-679.0 | 1" | SAE J609b | 3100 | 1425 | 7 | 2.176 | NHDP Car Wash, NHDP 200 |
| 1.904-906.0 | 1" | SAE J609b | 3100 | 1425 | 13 | 2.176 | NMT, NPM, NMT Nickel-Plated, NPM Nickel-Plated |
| 1.904-905.0 | 1" | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350, XXT, NLTI, PXI 500, PXI Heavy Duty |
| 1.904-904.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350, XXT, NLTI, PXI 500, PXI Heavy Duty |
| 1.904-903.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 23 | 2.176 | XLTI, PXI 350, XXT, PXI 500, PXI Heavy Duty |
P.T.O. multiplier
P.T.O. multiplier gear box
| CODE | INLET TORQUE | OUTLET TORQUE | INLET SPEED | OUTLET SPEED | NOTES | MAX POWER | RATIO | FOR PUMP SERIES |
|---|---|---|---|---|---|---|---|---|
| NM | NM | RPM | RPM | KW | N1 / N2 | |||
| 1.099-670.0 | 152 | 76 | 540 | 1080 | only for NLT2525S max 200 Bar | 9.4 | 2 | NLTI |
VBT
Head-mounted unloader valve with by-pass
Max 25 lpm & 275 bar
| CODE | FLOW RATE | MAX PRESSURE | INLET | OUTLET | FOR PUMP SERIES | ||
|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | BAR | PSI | ||||
| 1.099-494.0 | 25 | 6.6 | 100 | 1450 | G 1/2 F | G 3/8 M | FOG, FOG NEMA |
| 1.099-485.0 | 25 | 6.6 | 210 | 3045 | G 1/2 F | G 3/8 M | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA |
| 1.099-486.0 | 25 | 6.6 | 210 | 3000 | G 1/2 F | G 3/8 M | NMT, NMT Nickel-Plated, NMT-HY |
| 1.099-487.0 | 25 | 6.6 | 275 | 4000 | G 1/2 F | G 3/8 M | NPM, NPM-GR, NPM Nickel-Plated, NPM-HY |
Pump feet
Pump feet
| CODE | FOR PUMP SERIES |
|---|---|
| 1.099-687.0 | NMT, NPM, NMT Car Wash, NMT High Temperature, NMT Nickel-Plated, NPM Nickel-Plated, NHDP-HY, NMT - Car Wash Heavy Duty, NMT Chemical, NMT-HY, NPM-HY |
Pulsation dumpener
| CODE | FOR PUMP SERIES |
|---|---|
| 1.904-254.0 | NMT, NMT Car Wash, NMT High Temperature, NMT Nickel-Plated, NLTI, NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NMT - Car Wash Heavy Duty, NHDP 200-NEMA, NMT Chemical, NHDP Chemical, NHDP Stainless Steel Chemical, Complete Electric Motopumps Units NMT |
| 1.904-213.0 | XLTI, XLTI High Temperature, NLTI, XLTI Chemical, XLTI Stainless Steel Chemical |
Magnetic clutch
Magnetic clutch
| CODE | FOR PUMP SERIES |
|---|---|
| 1.099-657.0 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200 |
| 1.099-656.0 | NMT, NPM, NMT Car Wash, NMT High Temperature, NMT Nickel-Plated, NPM Nickel-Plated, NMT - Car Wash Heavy Duty, NMT Chemical |
Ordinary Maintenance Tool Kit
Tool kit for ordinary maintenance
| CODE | FOR PUMP SERIES |
|---|---|
| 9.853-525.0 | FOG, FOG NEMA |
| 1.904-744.0 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA, NMT Chemical, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.099-667.0 | NMT, NPM, NPM-GR, NMT Car Wash, NMT High Temperature, NMT Nickel-Plated, NPM Nickel-Plated, NMT - Car Wash Heavy Duty, Complete Electric Motopumps Units NMT |
| 1.099-665.0 | XLTI, XLTI High Temperature, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT High Temperature, XLTI Chemical, XLTI Stainless Steel Chemical |
Extraordinary maintenance Kit
| CODE | FOR PUMP SERIES |
|---|---|
| 1.905-591.0 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.904-414.0 | NMT, NPM, NPM-GR, NMT Car Wash, NMT High Temperature, NMT Nickel-Plated, NPM Nickel-Plated, NMT - Car Wash Heavy Duty, NMT Chemical, Complete Electric Motopumps Units NMT |
| 1.905-659.0 | XLTI, XLTI High Temperature, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT High Temperature, XLTI Chemical |
