Hidrolimpiadoras alta presión
Bombas para Hidrolimpiadoras alta presión
Accesorios para Hidrolimpiadoras alta presión
Bridas
Bridas para acoplamiento a motores eléctricos
| CODIGO | FORMA CONSTRUCTIVA MOTOR | PARA SERIE BOMBAS |
|---|---|---|
| 1.099-528.0 | H90 B14 | NHD 150 bar, NHD 200 bar, NHD 120 bar, NHDP Car Wash |
| 1.099-529.0 | H100/112 B14 | NHD 150 bar, NHD 200 bar, NHD 120 bar, NHDP Car Wash |
| 1.099-530.0 | H100/112 B14 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, NLTI, NMT-Special Brass |
| 1.099-531.0 | H132 B14 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XLTI Stainless Steel, NMT-Special Brass |
| 1.099-532.0 | H160 B5 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, XLTI Atex, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel |
Flexible coupling
Flexible couplings for electic motors
| CODIGO | FORMA CONSTRUCTIVA MOTOR | Ø T.D.F. MOTOR | Ø T.D.F. BOMBA | PARA SERIE BOMBAS |
|---|---|---|---|---|
| 1.099-541.0 | H100/112 | 28 mm | 24 mm | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, XLTI, NMT Stainless Steel, XLTI Alta Temperatura, NLTI, XLTI Atex, XLTI Stainless Steel, NMT-Special Brass |
| 1.099-542.0 | H90 | 24 mm | 24 mm | NHD 150 bar, NHD 200 bar, NHD 120 bar, NHDP Car Wash |
| 1.099-543.0 | H100/112 | 28 mm | 24 mm | NHD 150 bar, NHD 200 bar, NHD 120 bar, NHDP Car Wash |
| 1.099-544.0 | H90 | 24 mm | 24 mm | NMT, NMT Alta Temperatura, NMT Niquelada, NMT Stainless Steel, NMT-Special Brass |
| 1.099-545.0 | H132 | 38 mm | 24 mm | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, XLTI, NMT Stainless Steel, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XLTI Stainless Steel, NMT-Special Brass |
| 1.905-890.0 | H160 | 42 mm | 24 mm | XLTI, PXI 350, XXT, XLTI Atex, PXI 500, XXT Alta Temperatura |
Motore eléctrico arbol hueco
Motores eléctricos arbol hueco
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-397.0 | IEC112 | 32.0 | 7.5 | 5.5 | 1450 | 230/400V | NMT, NPM, NMT Car Wash, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, NMT-Special Brass |
| 1.099-398.0 | IEC100 | 22.0 | 5.5 | 4.0 | 1450 | 230/400V | NHD 150 bar, NHD 200 bar, NHDP Car Wash |
| 1.099-399.0 | IEC100 | 21.0 | 4.0 | 3.0 | 1450 | 230/400V | NHD 150 bar, NHD 200 bar, NHD 120 bar, NHDP Car Wash |
| 1.099-401.0 | IEC132M | 48.0 | 10.0 | 7.5 | 1450 | 230/400V | NMT, NPM, NMT Car Wash, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, PXI 350, NLTI, PXI 500, NMT-Special Brass |
| 1.099-402.0 | IEC132M | 53.0 | 12.5 | 9.2 | 1450 | 230/400V | NMT, NPM, NMT Niquelada, NPM Niquelada, XLTI, NMT Stainless Steel, PXI 350, NLTI, PXI 500, NMT-Special Brass |
| 1.099-407.0 | IEC100 | 22.0 | 5.5 | 4.0 | 1450 | 230/400V | NMT, NMT Car Wash, NMT Niquelada, NMT Stainless Steel, NMT-Special Brass |
| 1.099-409.0 | IEC132M | 56.0 | 15.0 | 11.0 | 1450 | 230/400V | XLTI, PXI 350, NLTI, PXI 500 |
| 1.099-410.0 | IEC100 | 22.0 | 3.0 | 2.2 | 1450 | 230V | NHD 150 bar, NHD 120 bar |
| 1.099-448.0 | IEC112 | 32.0 | 7.5 | 5.5 | 1450 | 230-400V | NHD 200 bar, NHDP Car Wash |
Motore eléctrico brida double
Motores eléctricos brida doble
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-432.0 | IEC160L | 100 | 20.0 | 15.0 | 1450 | 400/690V | XLTI, XLTI Alta Temperatura, PXI 350, XXT, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel |
| 1.099-433.0 | IEC160L | 112 | 25.0 | 18.5 | 1450 | 400/690V | XLTI, PXI 350, XXT, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel |
B3 / B14
B3 / B14 Versión del motor eléctrico
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-412.0 | IEC100 | 3.0 | 2.2 | 1450 RPM | 230/400 V | TMP-C | |
| 1.099-413.0 | IEC100 | 32.0 | 4.0 | 3.0 | 1450 | 230/400V | NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel, NHD-C 150 bar, NHD-C 200 bar, NHD-C 120 bar, NMT-Special Brass |
| 1.099-414.0 | IEC100 | 32.0 | 5.5 | 4.0 | 1450 | 230/400V | NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel, NHD-C 150 bar, NHD-C 200 bar, NMT-Special Brass |
| 1.099-416.0 | IEC112 | 48.0 | 7.5 | 5.5 | 1450 | 230/400V | NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel, XLTI Alta Temperatura, NHD-C 200 bar, NMT-Special Brass |
| 1.099-422.0 | IEC90L | 53.0 | 2.0 | 1.5 | 1450 | 230V | FOG |
| 1.099-430.0 | IEC80 | 32.0 | 0.75 | 0.55 | 1450 | 230V | FOG |
| 1.099-437.0 | IEC80 | 32.0 | 1.0 | 0.75 | 1450 | 230V | FOG |
| 1.099-438.0 | IEC90S | 48.0 | 1.5 | 1.1 | 1450 | 230V | FOG |
Reductores Gear-Box
Reductores para motores de explosión
| CODIGO | MOTOR SHAFT DIAMETER | BRIDA MOTOR | REV. ENTRADA | REV. SALIDA | POTENCIA MAX | RELACIÓN | PARA SERIE BOMBAS |
|---|---|---|---|---|---|---|---|
| Ø | TIPO | RPM | RPM | KW | N1 / N2 | ||
| 1.099-673.0 | 1" | SAE J609b | 3100 | 1425 | 13 | 2.176 | NMT, NPM, NMT Niquelada, NPM Niquelada, NMT-Special Brass |
| 1.099-675.0 | 3/4" | SAE J609a | 3400 | 1450 | 4.8 | 2.3 | NHD 150 bar, NHD 120 bar |
| 1.099-676.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350, XXT, NLTI, PXI 500 |
| 1.099-677.0 | 1" | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350, XXT, NLTI, PXI 500 |
| 1.099-678.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 23 | 2.176 | XLTI, PXI 350, XXT, PXI 500 |
| 1.099-679.0 | 1" | SAE J609b | 3100 | 1425 | 7 | 2.176 | NHD 200 bar |
Multiplicador
Multiplicador
| CODIGO | PAR ENTRADA | PAR SALIDA | REV. ENTRADA | REV. SALIDA | NOTAS | POTENCIA MAX | RELACIÓN | PARA SERIE BOMBAS |
|---|---|---|---|---|---|---|---|---|
| NM | NM | RPM | RPM | KW | N1 / N2 | |||
| 1.099-670.0 | 152 | 76 | 540 | 1080 | only for NLT2525S max 200 Bar | 9.4 | 2 | NLTI |
VBT
Válvula de regulación para fijación de tornillos huecos al cabezal bomba Max lpm 25
| CODIGO | CAUDAL | PRESIÓN MAX | ENTRADA | SALIDA | PARA SERIE BOMBAS | ||
|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | BAR | PSI | ||||
| 1.099-485.0 | 25 | 6.6 | 210 | 3045 | G 1/2 F | G 3/8 M | NHD 150 bar, NHD 200 bar, NHD-C 150 bar, NHD-C 200 bar, NHD 120 bar, NHD-C 120 bar, NHD-G, NHD-G1, NHD-HY, NHD-N, NHDP Car Wash |
| 1.099-486.0 | 25 | 6.6 | 210 | 3000 | G 1/2 F | G 3/8 M | NMT, NMT Niquelada |
| 1.099-487.0 | 25 | 6.6 | 275 | 4000 | G 1/2 F | G 3/8 M | NPM, NPM-GR, NPM Niquelada |
| 1.099-494.0 | 25 | 6.6 | 100 | 1450 | G 1/2 F | G 3/8 M | FOG, FOG-N |
Pies pompe
Pies pompe
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.099-687.0 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, NHD-HY, NMT-Special Brass |
Pulsation dumpener
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.904-213.0 | XLTI, NLTI |
| 1.904-254.0 | NMT, NLTI, NHD 150 bar, NHD 200 bar, NHD 120 bar |
Magnetic clutch
Magnetic clutch
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.099-656.0 | NMT, NPM |
| 1.099-657.0 | NHD 150 bar, NHD 200 bar, NHD 120 bar |
Maletín de Herramientas
Maletín de Herramientas Kit for Hot-water and Inox
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.099-665.0 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel |
| 1.099-667.0 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel |
| 1.099-668.0 | NHD 150 bar, NHD 200 bar, NHD 120 bar |
| 9.853-525.0 | FOG, FOG-N |
Kit de mantenimiento extraordinario
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.904-414.0 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel |
| 1.905-591.0 | NHD 150 bar, NHD 200 bar, NHD 120 bar |
| 1.905-659.0 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XLTI Stainless Steel |
