Bridas
Bridas para acoplamiento a motores eléctricos
| CODIGO | FORMA CONSTRUCTIVA MOTOR | PARA SERIE BOMBAS |
|---|---|---|
| 1.099-531.0 | H132 B14 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, XLTI Alta Temperatura, PXI 350 bar, XXT, NLTI, XLTI Atex, PXI 500 bar, XLTI Stainless Steel, NMT-Special Brass |
| 1.099-532.0 | H160 B5 | XLTI, XLTI Alta Temperatura, PXI 350 bar, XXT, XLTI Atex, PXI 500 bar, XXT Alta Temperatura, XLTI Stainless Steel |
Flexible coupling
Flexible couplings for electic motors
| CODIGO | FORMA CONSTRUCTIVA MOTOR | Ø T.D.F. MOTOR | Ø T.D.F. BOMBA | PARA SERIE BOMBAS |
|---|---|---|---|---|
| 1.099-545.0 | H132 | 38 mm | 24 mm | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, XLTI, NMT Stainless Steel, XLTI Alta Temperatura, PXI 350 bar, XXT, NLTI, XLTI Atex, PXI 500 bar, XLTI Stainless Steel, NMT-Special Brass |
| 1.099-744.0 | H160 | 42 mm | 24 mm | XLTI, PXI 350 bar, XXT, PXI 500 bar |
| 1.099-746.0 | H160 | 42 mm | 30 mm | MXT, MPX 350 bar, MPX 500 bar |
| 1.099-747.0 | H180 | 48 mm | 30 mm | MXT, MPX 350 bar, MPX 500 bar |
| 1.904-745.0 | IEC225 | 40 mm | 60 mm | HFR, GXT |
| 1.905-745.0 | H225 | 60 | 40 | HHP 500 bar - 1000 rpm, HHP 500 Bar - 1450 rpm, GPX |
| 9.853-748.0 | H200 | 55 mm | 30 mm | MXT, MPX 350 bar, MPX 500 bar |
Kit bridas y acoplamientos hidráulicos
Kit de bridas y acoplamientos para motores hidráulicos
| CODIGO | FORMA CONSTRUCTIVA MOTOR | Ø T.D.F. MOTOR | Ø T.D.F. BOMBA | PARA SERIE BOMBAS |
|---|---|---|---|---|
| 1.905-536.0 | SAE J744 B-B | 1'' | 30 | MXT, MXT Alta Temperatura, MPX 350 bar, MPX 500 bar |
| 1.905-537.0 | SAE J744 C | 1'' 1/4 | 40 | HFR, HHP 500 bar - 1000 rpm, HHP 500 Bar - 1450 rpm, GXT, GXT Alta temperatura, GPX |
| 1.905-732.0 | SAE J744 B | 7/8'' | 24 | XLTI, XLTI Alta Temperatura, PXI 350 bar, XXT, PXI 500 bar, XXT Alta Temperatura, XLTI Stainless Steel |
Motore eléctrico arbol hueco
Motores eléctricos arbol hueco
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-401.0 | IEC132M | 48.0 | 10.0 | 7.5 | 1450 | 230/400V | NMT, NPM, NMT Car Wash, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, PXI 350 bar, NLTI, PXI 500 bar, NMT-Special Brass |
| 1.099-402.0 | IEC132M | 53.0 | 12.5 | 9.2 | 1450 | 230/400V | NMT, NPM, NMT Niquelada, NPM Niquelada, XLTI, NMT Stainless Steel, PXI 350 bar, NLTI, PXI 500 bar, NMT-Special Brass |
| 1.099-409.0 | IEC132M | 56.0 | 15.0 | 11.0 | 1450 | 230/400V | XLTI, PXI 350 bar, NLTI, PXI 500 bar |
Motore eléctrico brida double
Motores eléctricos brida doble
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-432.0 | IEC160L | 100 | 20.0 | 15.0 | 1450 | 400/690V | XLTI, XLTI Alta Temperatura, PXI 350 bar, XXT, PXI 500 bar, XXT Alta Temperatura |
| 1.099-433.0 | IEC160L | 112 | 25.0 | 18.5 | 1450 | 400/690V | XLTI, PXI 350 bar, XXT, PXI 500 bar, XXT Alta Temperatura |
| 1.099-450.0 | IEC160L | 117 | 30 | 22 | 1450 | 400/690V | PXI 350 bar, XXT, PXI 500 bar |
| 1.099-452.0 | IEC180L | 150 | 40 | 30 | 1450 | 400/690V | MXT, MXT Alta Temperatura, MPX 350 bar, MPX 500 bar |
Reductores Gear-Box
Reductores para motores de explosión
| CODIGO | MOTOR SHAFT DIAMETER | BRIDA MOTOR | REV. ENTRADA | REV. SALIDA | POTENCIA MAX | RELACIÓN | PARA SERIE BOMBAS |
|---|---|---|---|---|---|---|---|
| Ø | TIPO | RPM | RPM | KW | N1 / N2 | ||
| 1.099-676.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350 bar, XXT, NLTI, PXI 500 bar |
| 1.099-677.0 | 1" | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350 bar, XXT, NLTI, PXI 500 bar |
| 1.099-678.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 23 | 2.176 | XLTI, PXI 350 bar, XXT, PXI 500 bar |
