Bridas
Bridas para acoplamiento a motores eléctricos
| CODIGO | FORMA CONSTRUCTIVA MOTOR | PARA SERIE BOMBAS |
|---|---|---|
| 1.099-528.0 | H90 B14 | NHD 150 bar, NHD 200 bar, NHD 120 bar, NHDP Car Wash |
| 1.099-529.0 | H100/112 B14 | NHD 150 bar, NHD 200 bar, NHD 120 bar, NHDP Car Wash |
| 1.099-530.0 | H100/112 B14 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, NLTI, NMT-Special Brass |
| 1.099-531.0 | H132 B14 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, XLTI Alta Temperatura, PXI 350 bar, XXT, NLTI, XLTI Atex, PXI 500 bar, XLTI Stainless Steel, NMT-Special Brass |
| 1.099-532.0 | H160 B5 | XLTI, XLTI Alta Temperatura, PXI 350 bar, XXT, XLTI Atex, PXI 500 bar, XXT Alta Temperatura, XLTI Stainless Steel |
Flexible coupling
Flexible couplings for electic motors
Kit bridas y acoplamientos hidráulicos
Kit de bridas y acoplamientos para motores hidráulicos
| CODIGO | FORMA CONSTRUCTIVA MOTOR | Ø T.D.F. MOTOR | Ø T.D.F. BOMBA | PARA SERIE BOMBAS |
|---|---|---|---|---|
| 1.905-536.0 | SAE J744 B-B | 1'' | 30 | MXT, MXT Alta Temperatura, MPX 350 bar, MPX 500 bar |
| 1.905-732.0 | SAE J744 B | 7/8'' | 24 | XLTI, XLTI Alta Temperatura, PXI 350 bar, XXT, PXI 500 bar, XXT Alta Temperatura, XLTI Stainless Steel |
Motore eléctrico arbol hueco
Motores eléctricos arbol hueco
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-397.0 | IEC112 | 32.0 | 7.5 | 5.5 | 1450 | 230/400V | NMT, NPM, NMT Car Wash, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, NMT-Special Brass |
| 1.099-398.0 | IEC100 | 22.0 | 5.5 | 4.0 | 1450 | 230/400V | NHD 150 bar, NHD 200 bar, NHDP Car Wash |
| 1.099-399.0 | IEC100 | 21.0 | 4.0 | 3.0 | 1450 | 230/400V | NHD 150 bar, NHD 200 bar, NHD 120 bar, NHDP Car Wash |
| 1.099-401.0 | IEC132M | 48.0 | 10.0 | 7.5 | 1450 | 230/400V | NMT, NPM, NMT Car Wash, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, PXI 350 bar, NLTI, PXI 500 bar, NMT-Special Brass |
| 1.099-402.0 | IEC132M | 53.0 | 12.5 | 9.2 | 1450 | 230/400V | NMT, NPM, NMT Niquelada, NPM Niquelada, XLTI, NMT Stainless Steel, PXI 350 bar, NLTI, PXI 500 bar, NMT-Special Brass |
| 1.099-407.0 | IEC100 | 22.0 | 5.5 | 4.0 | 1450 | 230/400V | NMT, NMT Car Wash, NMT Niquelada, NMT Stainless Steel, NMT-Special Brass |
| 1.099-409.0 | IEC132M | 56.0 | 15.0 | 11.0 | 1450 | 230/400V | XLTI, PXI 350 bar, NLTI, PXI 500 bar |
| 1.099-448.0 | IEC112 | 32.0 | 7.5 | 5.5 | 1450 | 230-400V | NHD 200 bar, NHDP Car Wash |
Motore eléctrico brida double
Motores eléctricos brida doble
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-432.0 | IEC160L | 100 | 20.0 | 15.0 | 1450 | 400/690V | XLTI, XLTI Alta Temperatura, PXI 350 bar, XXT, PXI 500 bar, XXT Alta Temperatura |
| 1.099-433.0 | IEC160L | 112 | 25.0 | 18.5 | 1450 | 400/690V | XLTI, PXI 350 bar, XXT, PXI 500 bar, XXT Alta Temperatura |
| 1.099-450.0 | IEC160L | 117 | 30 | 22 | 1450 | 400/690V | PXI 350 bar, XXT, PXI 500 bar |
| 1.099-452.0 | IEC180L | 150 | 40 | 30 | 1450 | 400/690V | MXT, MXT Alta Temperatura, MPX 350 bar, MPX 500 bar |
B3 / B14
B3 / B14 Versión del motor eléctrico
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-413.0 | IEC100 | 32.0 | 4.0 | 3.0 | 1450 | 230/400V | NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel, NHD-C 150 bar, NHD-C 200 bar, NHD-C 120 bar, NMT-Special Brass |
| 1.099-414.0 | IEC100 | 32.0 | 5.5 | 4.0 | 1450 | 230/400V | NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel, NHD-C 150 bar, NHD-C 200 bar, NMT-Special Brass |
| 1.099-416.0 | IEC112 | 48.0 | 7.5 | 5.5 | 1450 | 230/400V | NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel, XLTI Alta Temperatura, NHD-C 200 bar, NMT-Special Brass |
Reductores Gear-Box
Reductores para motores de explosión
| CODIGO | MOTOR SHAFT DIAMETER | BRIDA MOTOR | REV. ENTRADA | REV. SALIDA | POTENCIA MAX | RELACIÓN | PARA SERIE BOMBAS |
|---|---|---|---|---|---|---|---|
| Ø | TIPO | RPM | RPM | KW | N1 / N2 | ||
| 1.099-673.0 | 1" | SAE J609b | 3100 | 1425 | 13 | 2.176 | NMT, NPM, NMT Niquelada, NPM Niquelada, NMT-Special Brass |
| 1.099-676.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350 bar, XXT, NLTI, PXI 500 bar |
| 1.099-677.0 | 1" | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350 bar, XXT, NLTI, PXI 500 bar |
| 1.099-678.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 23 | 2.176 | XLTI, PXI 350 bar, XXT, PXI 500 bar |
| 1.099-679.0 | 1" | SAE J609b | 3100 | 1425 | 7 | 2.176 | NHD 200 bar |
VBT
Válvula de regulación para fijación de tornillos huecos al cabezal bomba Max lpm 25
| CODIGO | NOTAS | CAUDAL | PRESIÓN MAX | ENTRADA | SALIDA | PARA SERIE BOMBAS | ||
|---|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | BAR | PSI | |||||
| 1.099-485.0 | 25 | 6.6 | 210 | 3045 | G 1/2 F | G 3/8 M | NHD 150 bar, NHD 200 bar, NHD-C 150 bar, NHD-C 200 bar, NHD 120 bar, NHD-C 120 bar, NHD-G, NHD-G1, NHD-HY, NHD-N, NHDP Car Wash | |
| 1.099-486.0 | 25 | 6.6 | 210 | 3000 | G 1/2 F | G 3/8 M | NMT, NMT Niquelada | |
| 1.099-487.0 | 25 | 6.6 | 275 | 4000 | G 1/2 F | G 3/8 M | NPM, NPM-GR, NPM Niquelada | |
Pies pompe
Pies pompe
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.099-687.0 | NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, NHD-HY, NMT-Special Brass |
