Nebulización
Bombas para Nebulización
Accesorios para Nebulización
Motore eléctrico arbol hueco
Motores eléctricos arbol hueco
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-410.0 | IEC100 | 20.0 | 3.0 | 2.2 | 1450 | 230V | NHDP 120, NHDP 150 |
| 1.099-399.0 | IEC100 | 20.0 | 4.0 | 3.0 | 1450 | 230/400V | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200 |
| 1.099-398.0 | IEC100 | 22.0 | 5.5 | 4.0 | 1450 | 230/400V | NHDP Car Wash, NHDP 150, NHDP 200 |
| 1.099-401.0 | IEC132M | 46.0 | 10.0 | 7.5 | 1450 | 230/400V | NMT, NPM, NMT Car Wash, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, PXI 350, NLTI, PXI 500, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical |
| 1.099-402.0 | IEC132M | 52.0 | 12.5 | 9.2 | 1450 | 230/400V | NMT, NPM, NMT Niquelada, NPM Niquelada, XLTI, NMT Stainless Steel, PXI 350, NLTI, PXI 500, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical, PXI Heavy Duty |
| 1.099-409.0 | IEC132M | 58.0 | 15.0 | 11.0 | 1450 | 230/400V | XLTI, PXI 350, NLTI, PXI 500, PXI Heavy Duty |
Motore eléctrico brida double
Motores eléctricos brida doble
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-432.0 | IEC160L | 96.0 | 20.0 | 15.0 | 1450 | 400/690V | XLTI, XLTI Alta Temperatura, PXI 350, XXT, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel, XLTI Chemical, XLTI Stainless Steel Chemical, PXI Heavy Duty |
| 1.099-433.0 | IEC160L | 100 | 25.0 | 18.5 | 1450 | 400/690V | XLTI, PXI 350, XXT, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel |
| 1.099-450.0 | IEC160L | 110 | 30 | 22 | 1450 | 400/690V | PXI 350, XXT, PXI 500, XLTI Stainless Steel, PXI Heavy Duty |
| 1.099-451.0 | IEC160L | 110 | 30 | 22 | 1450 | 400/690V | MXT, MXT Alta Temperatura, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty |
| 1.099-452.0 | IEC180L | 185 | 40 | 30 | 1450 | 400/690V | MXT, MXT Alta Temperatura, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty |
B3 / B14
B3 / B14 Versión del motor eléctrico
| CODIGO | FORMA CONSTRUCTIVA MOTOR | WEIGHT | RATED OUTPUT | SPEED | VOLTAJE | PARA SERIE BOMBAS | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-430.0 | IEC80 | 12.0 | 0.75 | 0.55 | 1450 | 230V | FOG |
| 1.099-437.0 | IEC80 | 12.0 | 1.0 | 0.75 | 1450 | 230V | FOG |
| 1.099-438.0 | IEC90S | 16.0 | 1.5 | 1.1 | 1450 | 230V | FOG |
| 1.099-422.0 | IEC90L | 16.0 | 2.0 | 1.5 | 1450 | 230V | FOG |
| 1.099-413.0 | IEC100 | 21.0 | 4.0 | 3.0 | 1450 | 230/400V | NMT Car Wash, NMT Alta Temperatura, NMT Stainless Steel, NHDP 120-C, NHDP 150-C, NHDP 200-C, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical |
Bridas
Bridas para acoplamiento a motores eléctricos
| CODIGO | FORMA CONSTRUCTIVA MOTOR | PARA SERIE BOMBAS |
|---|---|---|
| 1.099-528.0 | H90 B14 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200 |
| 1.099-529.0 | H100/112 B14 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200 |
| 1.099-530.0 | H100/112 B14 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, NLTI, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical |
| 1.099-531.0 | H132 B14 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, XLTI, NMT Stainless Steel, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XLTI Stainless Steel, NMT - Car Wash Heavy Duty, NMT Chemical, XLTI Chemical, XLTI Stainless Steel Chemical, NMT Stainless Steel Chemical, PXI Heavy Duty |
| 1.099-532.0 | H160 B5 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, XLTI Atex, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel, XLTI Chemical, XLTI Stainless Steel Chemical, PXI Heavy Duty |
Flexible coupling
Flexible couplings for electic motors
VBT
Válvula de regulación para fijación
de tornillos huecos al cabezal bomba
Max 25 lpm & 275 bar
| CODIGO | CAUDAL | PRESIÓN MAX | ENTRADA | SALIDA | PARA SERIE BOMBAS | ||
|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | BAR | PSI | ||||
| 1.099-494.0 | 25 | 6.6 | 100 | 1450 | G 1/2 F | G 3/8 M | FOG, FOG NEMA |
| 1.099-485.0 | 25 | 6.6 | 210 | 3045 | G 1/2 F | G 3/8 M | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA |
Pies pompe
Pies pompe
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.099-975.0 | MXT, MXT Alta Temperatura, MPX 350, MPX 500 |
Pulsation dumpener
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.904-254.0 | NMT, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NMT Stainless Steel, NLTI, NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NMT - Car Wash Heavy Duty, NHDP 200-NEMA, NMT Chemical |
| 1.904-213.0 | XLTI, XLTI Alta Temperatura, NLTI, XLTI Chemical, XLTI Stainless Steel Chemical |
Kit maletín mantenimiento ordinario
Maletín por el mantenimiento ordinario
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 9.853-525.0 | FOG, FOG NEMA |
| 1.904-744.0 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA, NMT Chemical |
| 1.099-665.0 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel, XLTI Chemical, XLTI Stainless Steel Chemical |
| 1.099-669.0 | MXT, MXT Alta Temperatura, MPX 350, MPX 500 |
| 1.905-635.0 | GXT, GXT Alta temperatura, GPX |
| 1.904-204.0 | HFR, HHP 500 - 1000 rpm, HHP 500 - 1450 rpm |
Kit de mantenimiento extraordinario
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.905-636.0 | GXT, GXT Alta temperatura, GPX |
| 1.904-418.0 | MXT, MXT Alta Temperatura, MPX 350, MPX 500 |
| 1.905-591.0 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA |
| 1.905-659.0 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel, XLTI Chemical |
