Municipalidad
Bombas para Municipalidad
Accesorios para Municipalidad
Motor hidráulico de engranaje
| CODIGO | CILINDRADA | OIL FLOW RATE AT 1450 RPM | PRESIóN MAX ACEITE | SPEED | ENTRADA | SALIDA | DRENAJE | PARA SERIE BOMBAS | ||
|---|---|---|---|---|---|---|---|---|---|---|
| cm3 rev | l/min | us gpm | BAR | PSI | RPM | |||||
| 1.905-828.0 | 24 | 33 | 8.7 | 170 | 2460 | 500-2000 | G 3/4'' | G 3/4'' | G 1/4'' | NHDP-HY, NMT-HY, NPM-HY |
| 9.853-808.0 | 44 | 59.9 | 15.8 | 250 | 3625 | 1000 - 3000 | G 1" 1/4 | G 1" 1/4 | G 3/8" | NLTI-HY, XLTI-HY |
| 9.853-809.0 | 52 | 71.5 | 19 | 230 | 3335 | 1000 - 2500 | G 1" 1/4 | G 1" 1/4 | G 3/8" | XXT-HY, PXI-HY |
| 9.853-811.0 | 71 | 97.6 | 25.8 | 200 | 2900 | 1000 - 2500 | G 1" 1/4 | G 1" 1/4 | G 3/8" | MXT-HY, MPX-HY |
Motor hidráulico de pistón
| CODIGO | CILINDRADA | OIL FLOW RATE AT 1450 RPM | PRESIóN MAX ACEITE | SPEED | ENTRADA | SALIDA | DRENAJE | PARA SERIE BOMBAS | ||
|---|---|---|---|---|---|---|---|---|---|---|
| cm3 rev | l/min | us gpm | BAR | PSI | RPM | |||||
| 9.853-812.0 | 47 | 68.5 | 18 | 350 | 5080 | 500 - 4000 | G 3/4'' | G 3/4'' | G 1/2" | MXT-HY, MPX-HY |
| 9.853-813.0 | 62 | 90.3 | 23.9 | 320 | 4640 | 500 - 4000 | G 3/4'' | G 3/4'' | G 1/2" | MXT-HY, MPX-HY |
Kit bridas y acoplamientos hidráulicos
Kit de bridas y acoplamientos para motores hidráulicos
| CODIGO | FORMA CONSTRUCTIVA MOTOR | Ø T.D.F. MOTOR | Ø T.D.F. BOMBA | PARA SERIE BOMBAS |
|---|---|---|---|---|
| 1.905-732.0 | SAE J744 B | 7/8'' | 24 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel, XLTI Chemical, XLTI Stainless Steel Chemical, PXI Heavy Duty |
| 1.905-536.0 | SAE J744 B-B | 1'' | 30 | MXT, MXT Alta Temperatura, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty |
| 1.905-537.0 | SAE J744 C | 1'' 1/4 | 40 | HFR, HHP 500 - 1000 rpm, HHP 500 - 1450 rpm, GXT, GXT Alta temperatura, GPX, TXT, TPX |
Reductores
Reductores para motores de explosión
| CODIGO | MOTOR SHAFT DIAMETER | BRIDA MOTOR | REV. ENTRADA | REV. SALIDA | POTENCIA MAX | RELACIÓN | PARA SERIE BOMBAS |
|---|---|---|---|---|---|---|---|
| Ø | TIPO | RPM | RPM | KW | N1 / N2 | ||
| 1.904-905.0 | 1" | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350, XXT, NLTI, PXI 500, PXI Heavy Duty |
| 1.904-904.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 17.7 | 2.176 | XLTI, PXI 350, XXT, NLTI, PXI 500, PXI Heavy Duty |
| 1.904-903.0 | 1"1/8 | SAE J609b | 3100 | 1425 | 23 | 2.176 | XLTI, PXI 350, XXT, PXI 500, PXI Heavy Duty |
Manómetro
Manómetro
| CODIGO | FIJACIÓN | ESCALA | ENTRADA | |
|---|---|---|---|---|
| BAR | PSI | |||
| 1.099-556.0 | Radial / Radiale | 250 | 3625 | G 1/4 M |
| 1.099-553.0 | Radial / Radiale | 315 | 4500 | G 1/4 M |
| 1.099-554.0 | Radial / Radiale | 400 | 5800 | G 1/4 M |
| 1.099-551.0 | Radial / Radiale | 600 | 8700 | G 1/4 M |
| 1.099-557.0 | Axial / Assiale | 160 | 2300 | G 1/4 M |
| 1.099-558.0 | Axial / Assiale | 250 | 3600 | G 1/4 M |
Pies pompe
Pies pompe
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.099-687.0 | NMT, NPM, NMT Car Wash, NMT Alta Temperatura, NMT Niquelada, NPM Niquelada, NMT Stainless Steel, NHDP-HY, NMT - Car Wash Heavy Duty, NMT Chemical, NMT-HY, NPM-HY |
Jetter valves
Jetter valves
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.904-265.0 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA |
| 1.904-285.0 | XLTI, XLTI Chemical |
| 1.904-266.0 | XLTI, XLTI Alta Temperatura, XLTI Stainless Steel Chemical |
| 9.851-994.0 | XXT |
Kit maletín mantenimiento ordinario
Maletín por el mantenimiento ordinario
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.904-744.0 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA, NMT Chemical |
| 1.099-665.0 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel, XLTI Chemical, XLTI Stainless Steel Chemical |
| 1.099-669.0 | MXT, MXT Alta Temperatura, MPX 350, MPX 500 |
| 1.905-635.0 | GXT, GXT Alta temperatura, GPX |
| 1.904-204.0 | HFR, HHP 500 - 1000 rpm, HHP 500 - 1450 rpm |
Kit de mantenimiento extraordinario
| CODIGO | PARA SERIE BOMBAS |
|---|---|
| 1.905-591.0 | NHDP Car Wash, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA |
| 1.905-659.0 | XLTI, XLTI Alta Temperatura, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT Alta Temperatura, XLTI Stainless Steel, XLTI Chemical |
| 1.904-418.0 | MXT, MXT Alta Temperatura, MPX 350, MPX 500 |
| 1.905-636.0 | GXT, GXT Alta temperatura, GPX |
