TXT Series
The pumps in the TXT series can operate at a maximum pressure of 250 bar, a flow rate of 220lpm, and a water temperature of up to 65° (149 F). This model is suitable for use on large vehicles for municipal cleaning services and other industrial applications for which its impressive flow rate can be exploited
TECHNICAL CHARACTERISTICS
| Weight | Kg | 74.5 |
| Oil capacity | lt. | 5.5 |
| Inlet | G | 2" |
| Outlet | G | 1" - 1 1/4" |
TECHNICAL CHARACTERISTICS
| Weight | Kg | 74.5 |
| Oil capacity | lt. | 5.5 |
| Inlet | G | 2" |
| Outlet | G | 1" - 1 1/4" |
Find out about all the models in the series TXT.
|
Part. No.
CODE |
Part. No.
CODE |
FLOW RATE | MAX PRESSURE | RPM | MAX POWER | TEMPERATURE | POWER TAKE-OFF | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | BAR | PSI | HP | KW | °C | °F | ||||
| TXT1225SL | 1.904-875.0 | 120 | 32 | 250 | 3625 | 1000 | 77.4 | 57.7 | 65 | 149 |
|
| TXT1225SR | 1.904-874.0 | 120 | 32 | 250 | 3625 | 77.4 | 57.7 | 65 | 149 |
|
|
| TXT1520SL | 1.904-873.0 | 150 | 40 | 200 | 3000 | 77.4 | 57.7 | 65 | 149 |
|
|
| TXT1520SR | 1.904-872.0 | 150 | 40 | 200 | 3000 | 77.4 | 57.7 | 65 | 149 |
|
|
| TXT1817SL | 1.904-871.0 | 180 | 48 | 170 | 2465 | 78.9 | 58.8 | 65 | 149 |
|
|
| TXT1817SR | 1.904-870.0 | 180 | 48 | 170 | 2465 | 78.9 | 58.8 | 65 | 149 |
|
|
| TXT2214SL | 1.904-869.0 | 220 | 58.7 | 140 | 2030 | 79.4 | 59.2 | 65 | 149 |
|
|
| TXT2214SR | 1.904-868.0 | 220 | 58.7 | 140 | 2030 | 79.4 | 59.2 | 65 | 149 |
|
|
Discover the related ACCESSORIES
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Flexible coupling
Flexible couplings for electic motors
| CODE | MOTOR CONTRUCTION SHAPE | MOTOR P.T.O. Ø | PUMP P.T.O. Ø | FOR PUMP SERIES |
|---|---|---|---|---|
| 1.904-313.0 | IEC225 | 60 mm | 40 mm | HFR, HHP 500 - 1000 rpm, HHP 500 - 1450 rpm, GXT, GXT High temperature, GPX, GXX, TXT, TPX, TXX |
| 1.904-757.0 | IEC250 | 65 mm | 40 mm | HFR, HHP 500 - 1000 rpm, GXT, GXT High temperature, GPX, GXX, TXT, TPX, TXX |
| 1.904-758.0 | IEC280 | 75 mm | 40 mm | GXT, GXT High temperature, GPX, GXX, TXT, TPX, TXX |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Hydraulic flanges and couplings kit
Flanges and couplings kit for hydraulic motors
| CODE | MOTOR CONTRUCTION SHAPE | MOTOR P.T.O. Ø | PUMP P.T.O. Ø | FOR PUMP SERIES |
|---|---|---|---|---|
| 1.905-537.0 | SAE J744 C | 1'' 1/4 | 40 | HFR, HHP 500 - 1000 rpm, HHP 500 - 1450 rpm, GXT, GXT High temperature, GPX, TXT, TPX |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Pressure Gauge
Hawk's water pressure gauge is a reliable and accurate instrument for monitoring pump pressure in high-pressure systems.
Available with radial or axial connection and G 1/4 M or G 1/2 M threads, it is designed to withstand pressures up to 1600 bar (23206 PSI). The available scales, from 160 to 1600 bar, cover a wide range of use, adapting to a variety of operational needs.
Thanks to its quality construction and the availability of INOX-ATEX versions, this high-pressure gauge is also suitable for complex and potentially explosive environments. Its high strength and measurement accuracy make it ideal for many professional applications.
Rugged, accurate and versatile, the Hawk pressure gauge is the perfect solution for ensuring consistent water pressure control in any type of professional facility.
| CODE | COUPLING | SCALE | INLET | |
|---|---|---|---|---|
| BAR | PSI | |||
| 1.099-556.0 | Radial / Radiale | 250 | 3625 | G 1/4 M |
| 1.099-553.0 | Radial / Radiale | 315 | 4500 | G 1/4 M |
| 1.099-554.0 | Radial / Radiale | 400 | 5800 | G 1/4 M |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Ordinary Maintenance Tool Kit
Tool kit for ordinary maintenance
| CODE | FOR PUMP SERIES |
|---|---|
| 1.905-635.0 | GXT, GXT High temperature, GPX, TXT, TPX |
