Find out about all the models in the series ST.
|
Part. No.
CODE |
FLOW RATE | MAX PRESSURE | RPM | MAX POWER | TEMPERATURE | POWER TAKE-OFF | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | HP | KW | ||||||||||||
| 50Hz | 60Hz | 50Hz | 60Hz | BAR | PSI | 50Hz | 60Hz | 50Hz | 60Hz | 50Hz | 60Hz | °C | °F | ||
| HC200A | 8.5 | 10.2 | 2.2 | 2.7 | 120 | 1750 | 1450 | 1740 | 2.6 | 3.1 | 1.9 | 2.3 | - | - |
|
| HC200AL | 8.5 | 10.2 | 2.2 | 2.7 | 120 | 1750 | 2.6 | 3.1 | 1.9 | 2.3 | - | - |
|
||
| HC200AR | 8.5 | 10.2 | 2.2 | 2.7 | 120 | 1750 | 2.6 | 3.1 | 1.9 | 2.3 | - | - |
|
||
| HC240A | 11 | 13.1 | 2.9 | 3.5 | 120 | 1740 | 3.4 | 4.1 | 2.5 | 3 | - | - |
|
||
| HC240AL | 11 | 13.1 | 2.9 | 3.5 | 120 | 1740 | 3.4 | 4.1 | 2.5 | 3 | - | - |
|
||
| HC240AR | 11 | 13.1 | 2.9 | 3.5 | 120 | 1740 | 3.4 | 4.1 | 2.5 | 3 | - | - |
|
||
| HC240I | 12 | 14.7 | 3.2 | 3.8 | 120 | 1740 | 3.6 | 4.4 | 2.7 | 3.2 | - | - |
|
||
| HC240IL | 12 | 14.7 | 3.2 | 3.8 | 120 | 1740 | 3.6 | 4.4 | 2.7 | 3.2 | - | - |
|
||
| HC240IR | 12 | 14.7 | 3.2 | 3.8 | 120 | 1740 | 3.6 | 4.4 | 2.7 | 3.2 | - | - |
|
||
| HC280A | 14 | 16.7 | 3.7 | 4.4 | 120 | 1740 | 4.3 | 5.1 | 3.2 | 3.8 | 65 | - |
|
||
| HC280AL | 14 | 16.7 | 3.7 | 4.4 | 120 | 1740 | 4.3 | 5.1 | 3.2 | 3.8 | - | - |
|
||
| HC280AR | 14 | 16.7 | 3.7 | 4.4 | 120 | 1740 | 4.3 | 5.1 | 3.2 | 3.8 | - | - |
|
||
